Description
PRODUCT SPECIFICATIONS
| MODEL NO | FC-M7100-1 |
|---|---|
| SERIES | SLX M7100 Series |
| Color | Series color |
| Average weight | 634 (30T) 631 (32T) 646 (34T) |
| Rear speeds | 12 |
|---|---|
| Compatible chain | HG 12-speed |
| Chain line (mm) | 52 |
| O.L.D.|Thru (mm) | 142, 148 |
| O.L.D.|QR/Nut (mm) | 135, 141 |
| P.C.D. (mm) | Direct |
| Spider/gear arms | 4 |
| Chainring combination | 30T, 32T, 34T |
| Q-factor (mm) | 172 |
| Crank arm length (mm)|165 | ✔ |
| Crank arm length (mm)|170 | ✔ |
| Crank arm length (mm)|175 | ✔ |
| Optional chain guard|Without chain/bash guard | ✔ |
| HOLLOWTECH II | ✔ |
| Compatible bottom bracket type|Outboard | ✔ |
| Recommended bottom bracket|Threaded (normal) | BB-MT801 |
| Recommended bottom bracket|Press-Fit | BB-MT800-PA |
| Threaded bottom bracket shell width (mm)|68 | ✔ |
| Threaded bottom bracket shell width (mm)|73 | ✔ |
| Crank fixing screw included | ✔ |
