Description

SPECIFICATIONS:

Application: Cross Country, City & Touring, City
Type: hydraulic, 2 pistons
Actuation: mineral oil
Hose: SM-BH59-JK-SS
Line Length (Front/Rear): 1000 mm/1700 mm

TECHNICAL INFORMATION – CALLIPER:

Calliper Mount: post mount
Pistons: 2
Pads: B01S resin
Design: 2-piece
Calliper Material: aluminium
Hose Connection: straight

TECHNICAL INFORMATION – LEVER:

Lever Length: 3-finger
Adjustment Options: reach adjust (with tools)
Installation: clamp (closed)
Design: right (side-specific), left (side-specific)
Brake Lever Material: Steel
Brake Lever Housing Material: aluminium
Hose Connection: straight

FEATURES:

– versatile design suitable for a wide range of bike types
– braking power adapted to MTB beginners
– small hands can easily reach lever
– reliable, quieter braking performance
– easy, fast and clean installation
– reduced rattling noises of the brake hoses
– resin pistons
– IS mount with adapter possible
– recommended brake rotor: SM-RT10, SM-RT26
– painted brake calliper, steel bolts (5 mm)
– funnel bleeding
– lever and body painted, steel clamp bolt
– Shimano logo

TECHNOLOGY:

One-Way-Bleeding
One-Way Bleeding is designed to quickly and easily prevent air from entering the hydraulic system. Shimano has optimised the brake fluid flow path throughout the system to prevent air bubbles from being trapped in the system.
One way oil routing plus a funnel tool with mineral oil provides an easy and clean bleeding system.

MANUFACTURER PART NUMBER:

E-MT200KLFPRA100 + E-MT200KRRXRA170

CONTENTS:

– 2 x Shimano BR-MT200 + BL-MT200 disc brakes, front & rear (choose both variants separately for complete set)
– 1 x Shimano SM-BH59-JK-SS brake hose, 1000 mm (front)
– 1 x Shimano SM-BH59-JK-SS brake hose, 1700 mm (rear)
– 2 pair of Shimano B01S brake pads
– 2 x inserts
– 2 x olives
– 4 x calliper bolts
– 2 x snap ring
– ready to mount (filled & bled)
